SM-L300
SM-L300 Mobile Receipt PrinterSM-L304 Mobile Receipt Printer with MSR
Compact 3″ / 80mm Mobile Bluetooth Receipt and Label Printer
Compact and reliable mobile receipt and label printer from Star for POS and logistics applications. The easy-to-use SM-L300 with OLED display features Bluetooth 4.0 (BLE) connectivity as well as Classic Bluetooth allowing it to connect with multiple Apple iOS devices. This 80mm / 3 inch printer is useful for printing in-store / in-field receipts and reports on-the-go as well as printing variable width traditional & liner free re-stick labels for retail and logistics applications. It features reflective (black mark), transmissive and paper end sensors to accommodate fixed length receipts and standard labels as well as MAXStick repositionable adhesive technology, liner-free labels*.
Designed to work just as happily from a person’s belt as well as or from the 5V counter top cradle charger, this versatile printer with an unprecedented 43 hour battery life at 5 minute printing intervals ticks all the mobility boxes and can simply be charged using a micro USB cable. Star’s WebPRNT Browser, simplifying direct printing from the web along with Star’s PassPRNT print data relaying application provides software support to match this sophisticated mobile printer for easy integration. The SM-L300 mobile bluetooth printer is also compatible with Star Cloud Services and the AllReceipts Digital Receipting App.
*Contact Star for details
Features
- 3″/ 80mm mobile receipt and label printer
- Label support with Black Mark & transmissive sensors
- MAXStick™ repositionable adhesive technology, liner-free label support*
- 65 mm/second print speed
- Unprecedented 43 hour battery life at 5 minute printing intervals
- Classic Bluetooth & Bluetooth 4.0 BLE
- Bluetooth 4.0 allows the use of multiple iOS tablets as opposed to the traditional one-to-one
- High contrast OLED Display for improved visibility of printer status in store
- Unique “flat”, decurl receipt feature
- Unique micro USB charging
- 5V desktop cradle charger option
- Compatible with Star Cloud Services and AllReceipts Digital Receipting App8
* Contact Star for details
SM-L300 Specifications
| Max. Print Speed | 65mm/sec. (70mm paper feed speed) |
|---|---|
| Resolution | 203 dpi |
| No. of Columns | |
| Autocutter | Tear Bar |
| Paper Width | 80mm thermal paper rolls |
| Paper Thickness | 0.053 – 0.12mm / Restick: Max. 0.086mm / Label: Max. 0.150mm |
| Paper Roll Standard Option | 80mm wide (receipt or label printing), 57mm max roll diameter |
| Media Presentation | Horizontal desktop or vertical with belt strap |
| Print Width | 40mm to 72mm |
| Sensors | |
| Connectivity | Classic Bluetooth/Bluetooth Low Energy |
| Drop Test |
1.2m |
| Battery | DC7.4V Lithium-Ion Battery 2000mAh, USB charging |
| Battery Life |
43 hours with 5 minute print intervals |
| Reliability | 50km (37 million lines MCBF) |
| Dimensions (W x D x H) mm Weight | 119.1 (W) x 150.8 (L) x 69.0 (H) mm Weight 540g with battery |
| Included at Purchase |
|
| Options |
|
Image Gallery
SM-L300 Models
| Part Number | Model | Description |
| 39633200 | SM-L300-UB57 | 3″ 80mm Mobile Receipt Printer, Bluetooth 4.0 BLE, iOS, Android, includes battery and charger |
| 39633300 | SM-L304-UB57 | 3″ 80mm Mobile Receipt Printer with MSR, Bluetooth 4.0 BLE, iOS, Android, includes battery and charger |
| Accessories | ||
| 39569500 | Battery Pack L3 | Battery Pack |
| 39569490 | Charging Cradle SM-L300 | Desk Top Charging Cradle |
| 39593080 | USB Cable 1.0M W/Core 2 SM-L | USB Cable |
