TSP100IVSK
Compact, economical linerless label printer for PC, Network, Tablet and Cloud based systems
Versatile Direct Thermal Label Printer
Part of Star’s popular mCollection, the versatile mC-Label3 printer revolutionizes your work environment, offering unparalleled adapatibility and convenience.
Combining high quality, versatile thermal label printing with superior connectivity for PC, Network, Tablets and Cloud based systems, the mC-Label3 prints on a wide range of environmentally friendly liner-free media including low adhesive “re-stick” labels as well as high adhesive permanent and semi-permanent linerless labels. The mC-Print3 also prints traditional liner die-cut pre-sized labels as well as continuous label rolls and receipt paper.
Connected to Star Cloud Services, the mC-Label3 offers the ability to design, store and print multiple label templates with One Touch Label.
Printing high quality text, graphics and barcodes with fully adjustable label widths from 25mm to 80mm wide, the mC-Label3 can handle it all! With no ink or ribbons to change and with the very latest connectivity, the mC-Label3 is designed to offer unparalleled versatility.
The mC-Label3 is packed with useful features for simple operation. Adjustable paper width detectors ensure media is loaded correctly. Clear LEDs show printer and connectivity status and useful features enhance the user experience such as Star’s Paper taken sensor, which queues labels, preventing multiple labels printing before the previous label is taken. The multi-function button gives instant access to pre-made templates stored via Star’s Cloud Services.
As with all of Star’s mCollection, additional Star technologies are included. The new SteadyLAN+ technology offers a lightning-fast, stable internet connection to Android and Windows mobile devices connected to networked Star printers. In addition, new TetherLAN technology allows your 4G & 5G connected device to share its network connection with the mC-Label, essentially creating a CloudPRNT environment anywhere, anytime.
The mC-Label3 includes multiple connectivity options for Android and Windows devices: USB-C, Ethernet LAN, Bluetooth (MCL32CBI). The MCL32CBI is also Apple MFi-certified for iOS Bluetooth connectivity. Wireless LAN connectivity is also available with Star’s optional MCW10 WLAN adapter. Cloud and web based printing is simple using Star’s included CloudPRNT technology.
With Star Micronics Cloud Services, the mC-Label offers the flexibility to build, store, and print multiple static label templates and print them at the touch of a button. Simply use Star’s free label design software to design labels and print the stored label by pressing the multi-funtion button on the front with no device connection needed.
Additional USB-A ports enable USB devices to be simply connected and controlled via the printer. Connect a USB barcode scanner, scales or customer display.
View product specifications and technical information
Download product brochures and data sheets
View models and part numbers within the range
Drivers, product manuals, SDK information and FAQs
Compact, economical linerless label printer for PC, Network, Tablet and Cloud based systems
Durable and secure tablet stands and mounts for POS, Kiosk and Display
New generation 80mm thermal POS receipt printers with USB-C / USB-A and Ethernet LAN interfaces and Star CloudPRNT technology
Need product support or help with integration? Contact the Star team today and they will be happy to help!
A combination of sustainability, design and advanced technology
Star House Peregrine Business Park, Gomm Road, High Wycombe, Bucks
HP13 7DL, UK
| Technology | Direct Thermal Label Printer |
|---|---|
| Max. Print Speed | 180mm/sec. |
| Resolution | 8 dots/mm (203 dpi) |
| Media Support | Linerless labels (Restick and permanent), Die-cut labels, Continuous labels, Receipts |
| Autocutter | Guillotine (full and partial cut) |
| Paper Width | 24.5 to 79.5±0.5mm |
| Paper Roll diameter | Max. 102mm |
| Media Presentation | Front loading and paper presentation |
| Print Width | Adjustable 25mm to 80mm |
| Sensors | Taken sensor, Paper jam sensor, GAP/Black mark sensor, Paper end sensor, Cover open sensor, Paper position sensor, Paper width sensor |
| Paper Loading | Drop-In & Print |
| Connectivity |
|
| Power Supply | External PS65 100～240V AC±10% Power Supply |
| Power Consumption | At 24 VDC, room temperature, without USB power supply:During power ON idling: Approx. 0.08 A (average)
During ASCII printing: Approx. 2.1 A (average) |
| Emulation | StarPRNT |
| Reliability | Cutter Life: 200,000 cuts…Linerless label paper (Adhesive type: Strong adhesive)
One million cuts…Linerless label paper (Adhesive type: Weak adhesive) Head Life: 30 km (30 million pulses) … Linerless label paper (Adhesive type: Strong adhesive) 75 km (75 million pulses) …Linerless label paper (Adhesive type: Weak adhesive) IP22 splash resistant |
| Dimensions (W x D x H) mm Weight | 143 x 212 x 169mm |
| Software | Star CloudPRNT, Star WebPRNT, Star PassPRNT, StarXpand SDK, StarPRNT SDK |
| Included | AC Adapter Power Cable USB Cable (C-C 1m & C-A 1.8m) LAN Cable (1m) Simple Setup Sheet Safety Guide Self-Cleaning Paper Roll |
| Replacement Parts | Cutter Unit Platen Roll Unit 2 in 1 (Cutter unit & Platen unit set) |
| Options | 1D Barcode Scanner, MCW10 Wireless LAN Adapter, SCD222 Customer Display, mC-Sound Buzzer, BU01 Buzzer, CD4 Cash Drawer, CB2002 Cash Drawer, mUnite Tablet Stands |
| Part Number | Model | Description |
| 39658190 | MCL32CI BK E+U | mC-Label3 Direct Thermal Label and Linerless Printer, Adjustable Label Widths, Cutter, USB-C, Power Delivery for iOS / Android / Windows, Ethernet LAN, SteadyLAN, TetherLAN, CloudPRNT, Peripheral Hub, Grey Case, EU & UK Version, 24VDC Power Supply included |
| 39658390 | MCL32CBI BK E+U | mC-Label3 Direct Thermal Label and Linerless Printer, Adjustable Label Widths, Cutter, USB-C, Power Delivery for iOS / Android / Windows, Ethernet LAN, Bluetooth, SteadyLAN, TetherLAN, CloudPRNT, Peripheral Hub, Grey Case, EU & UK Version, 24VDC Power Supply included |
| Accessories | ||
| 39930000 | PS65AT-24A PSU | PS65 Power Supply for mC-Label3 MCL32CI/MCL32CBI Label Printer |
| 39594210 | MCL3 Platen | Replacement Platen Set for mC-Label3 MCL32CI/MCL32CBI Label Printer |
| 39594200 | MCL3 Cutter Set | Replacement Cutter for mC-Label3 MCL32CI/MCL32CBI Label Printer |
| 39594230 | MCL3 Cutter & Platen Set | Replacement Cutter and Platen Set for mC-Label3 MCL32CI/MCL32CBI Label Printer |
| 30907210 | MCW10 CO2 | Wireless LAN Adapter (Please check model and regions with Star) |
| 39594010 | MCS10 mC-Sound | mC-Sound Melody Buzzer Alert with 16 Sounds |
| 09990641 | Buzzer 104S120LFA | Buzzer Alert |
| 37964070 | TRP80-D102-C25PF 12 roll pack | Label Permanent Linerless MCL32C: 80mm Width, 80m Length, 12 Rolls/Case, Linerfree Label |
| 37964060 | TRP58-D102-C25PF 12 roll pack | Label Permanent Linerless MCL32C: 58mm Width, 80m Length, 12 Rolls/Case, Linerfree Label |
| 99250370 | MaxStick MS214170PLUSD-12 12 roll pack | MaxStick Restick Linerless 58 mm wide, 42.55m long, Diamond Pattern 12 Rolls/Case, Linerfree Label |
| 99250355 | MaxStick M318170PLUSD-12 12 roll pack | MaxStick Restick Linerless 80mm wide, 52 metres long, Diamond Pattern 12 Rolls/Case, Linerfree Label |
